Gloria All Gravel
Gravel · titanium · 6 sizes
Sign in and add the bike you ride, and this table will say what each size needs for your position.
Sign in
This is the bike I ride
No account is needed to read the table. Report a wrong number · Correct this bike
- Bike
- Gloria All Gravel · Gravel · titanium · 6 sizes · seatpost offsets 0 / 15 / 20 / 25 mm
- Geometry
- gloriacycling.com, fetched 28 Aug 2026, not yet re-checked
- Cockpit
- two-piece (Zipp Service Course / Gloria Ti stem), generic 70-130 stems, the maker's spec
- Solved with
- cover 10 mm (assumed), max spacers 40 mm (published), stem clamp centre 20 mm (assumed), so every verdict carries ±10 mm at the bar
- Sheet
- 6 September 2026 · 210 bikes, 43 makes, 1,262 sizes in the catalogue
Geometry, every size, from the maker's table
The tinted row is the size drawn beside it. Press a size to draw it.| Size | Stack (mm) | Reach (mm) | Head angle (deg) | Seat angle (deg) | Head tube (mm) | Chainstay (mm) | Wheelbase (mm) | Standover (mm)not published |
|---|---|---|---|---|---|---|---|---|
| 49 | 543.9 | 369 | 70 | 74 | 110 | 435 | 1020.8 | |
| 52 | 561.9 | 378 | 71 | 74 | 125 | 435 | 1026.4 | |
| 54 | 578 | 385 | 71.5 | 74 | 140 | 435 | 1033.9 | |
| 56 | 597 | 394 | 71.5 | 74 | 160 | 435 | 1049.2 | |
| 58 | 615.9 | 403 | 71.5 | 74 | 180 | 435 | 1064.6 | |
| 60 | 634.9 | 412 | 71.5 | 74 | 200 | 435 | 1079.9 |
The table runs on to the right: 6 more columns after Reach. Scroll it sideways to read them.
The 56 drawn to scale from the table, with no build on it. Stack and reach run from the bottom bracket to the top of the head tube; every size is solved from those two. One square is 100 mm.
The maker's cockpit
What each size is solved on unless you choose another bar on the sheet.Gloria two-piece (Zipp Service Course / Gloria Ti stem), generic 70-130 stemsStockstem -6 / 6 / -7 / 7 / -8 / 8 / -10 / 10 / -12 / 12 · reach 75 · lengths 70-130
In the maker's words
Kept whole, as I read it off gloriacycling.com.Not an integrated cockpit.
Cockpit and seatpost, in the maker's words · 205 words
Not an integrated cockpit. Frame ships with a standard external 44 mm headset: "Headset Included: 44mm, ZS44/28.6 upper, EC44/40 lower (Cane Creek 40)" on the frameset page (https://gloriacycling.com/products/frameset-gloria-titanium-all-gravel); the builder page adds "or FSA integrated ACR compatible" (https://gloriacycling.com/products/custom-titanium-gravel-bike-builder). Fork options on the frameset product: "External Cables + Cage Mounts", "Hidden Cables + Cage Mounts (+120 GBP)" (semi-integrated internal routing) or "RockShox Rudy Suspension (+200 GBP)" (40 mm travel, 12x100). Stems are conventional two-piece: stock builds use Zipp Service Course / Service Course SL alloy stem and bar (lengths and widths per size are NOT published on the build pages: https://gloriacycling.com/products/gloria-all-gravel-titanium-sram-force-axs-1x-zipp-303s-xplr-wheelset-copy and https://gloriacycling.com/products/gloria-all-gravel-titanium-sram-apex-axs-gx-mullet-dt-swiss-wheelset-copy). Gloria's own titanium stem is sold in 80, 90, 100, 110, 120 mm (https://gloriacycling.com/products/gloria-titanium-stem.js and https://gloriacycling.com/products/gloria-titanium-stem-brushed.js); stem angle not stated. Spacers: Gloria titanium spacers in 5 mm and 10 mm (https://gloriacycling.com/products/titanium-10mm-spacer.js); a "3D printed Spacer kit - Semi Integrated" is offered in Zipp Service Course stem compatible or Gloria titanium stem compatible versions for the hidden-cable fork (https://gloriacycling.com/products/3d-printed-spacer-kit-semi-integrated.js). A Zipp Service Course 70 Ergo handlebar 38 cm is listed as a product; bar reach, drop and flare are not stated on the Gloria site. Headset cover height not stated. Steerer: "1.5 inch to 1.1/8 inch tapered steerer full carbon disc fork" (frameset page).
IDENTIFICATION: The bike is the Gloria All Gravel (also written All-Gravel) by Gloria Cycling, a UK titanium brand (Crawley, West Sussex. Source: official manufacturer geometry chart (JPEG image embedded on the official site, read with the image reader)
How I read the maker's table
founded by Carlos Ramirez, formerly of Fulham, London per https://road.cc/content/feature/how-gloria-bikes-manages-compete-big-titanium-brands-316283). It is NOT the vintage Italian Gloria of Milan (Garibaldina etc.), which has no modern gravel model. Official site: https://gloriacycling.com. Collection page: https://gloriacycling.com/collections/gloria-all-gravel. Other current Gloria models (not collected): All Road (titanium road, geometry at https://gloriacycling.com/pages/geometry), All Terrain (titanium hardtail MTB, https://gloriacycling.com/pages/geometry-all-terrain) and an All World referenced on the collection page. There is only one All Gravel frame; it is sold as a frameset (from 1,499 GBP), several full builds (SRAM Apex AXS GX mullet / DT Swiss, Shimano GRX827 Di2, SRAM Apex AXS with RockShox Rudy fork, SRAM Force AXS 1x / Zipp 303s XPLR) and a custom builder (from 2,999 GBP); all share the same size range 49/52/54/56/58/60 and the same chart. GEOMETRY SOURCE: The official chart is a JPEG, https://cdn.shopify.com/s/files/1/0800/6329/9868/files/All-Gravel-Details-Landscape.jpg?v=1755525982 (v timestamp = Aug 2025), embedded on https://gloriacycling.com/pages/geometry-all-gravel and in the "Geometry" popup on the frameset, full-build and builder product pages; the identical chart also ships inside the official size-finder app (https://gloriatitaniumgravel.lovable.app/assets/geometry-chart-wn8LqGW3.jpg). All values were read directly from the image; units are mm and degrees as printed, no conversion needed. Rows in the chart: Seat Tube (C-T), Top Tube (C-C), Top Tube (Effective), Head Tube, Head Angle, Seat Angle, BB Drop, Chainstay, Fork Length, Fork Rake, Stack, Reach, Wheelbase. Extra rows not in the schema: Top Tube centre-to-centre = 506.8 / 519.9 / 530.9 / 545.2 / 561.3 / 573.7 (49 to 60); Fork Length (axle to crown) = 398 on all sizes. The chart does NOT publish standover, front centre, trail, seat tube angle type (effective vs actual), stem length or bar width, so those are null. Fork rake is printed as "47/52" for every size; the schema needs one number so 47 (the first value listed) is recorded, but treat it as two rake options (47 or 52 mm) - which one is fitted as standard is not stated (the official "Gloria Fork Data Sheet" page at https://gloriacycling.com/pages/gloria-fork-data-sheet renders no content without JavaScript). Model year: chart first appeared mid-2025 (frameset product published 2025-07-29 per its Shopify JSON); geometrygeeks and thegravelbikegeometryproject label it 2025; the July 2026 road.cc review quotes the same figures, so it is current for 2026. Minor discrepancy: road.cc (https://road.cc/offroad/review_v2/gloria-all-gravel-titanium-sram-force, 21 Jul 2026, size with 550.7 ETT = 54) quotes head angle 71 deg and wheelbase 1034 mm; the official chart says 71.5 deg and 1033.9 mm. Third-party derived values (not official, therefore not in the rows): thegravelbikegeometryproject.com (https://thegravelbikegeometryproject.com/bikes/gloria-all-gravel-2025.html) computes front centre 591/597/605/620/635/651 and trail 81/75/71/71/71/71 (49 to 60, 700x45 tyre); Bike Insights (https://bikeinsights.com/bikes/68968a1bb7008e001ae224c0-gloria-all-gravel?version=2025&build=base) gives trail 64.3-69.6 mm for the 47/52 rake pair on size 54. The geometrygeeks.bike page serves scrambled numbers without JavaScript and was not used. FRAME / SPEC (frameset page https://gloriacycling.com/products/frameset-gloria-titanium-all-gravel): "Frame tubing: Titanium Grade 3Al - 2.5V Aerospace Grade 9 Titanium", butted tubes; fork is full carbon with triple cage mounts, mudguard tabs and dynamo routing; frame weight ~2 kg, frameset ~2.5 kg (size 54 per build pages); finishes Sandblasted (standard), Anodised (+150 GBP), Brushed (+250 GBP); lifetime frame warranty; BSA 68 mm threaded BB; UDH hanger; thru-axles 12x100 front, 12x142 rear; flat mount brakes 140 or 160 mm rotors; rack and fender mounts. Seatpost diameter 31.6 mm ("Seat Post diameter: 31.6mm"), seatpost offset not stated (stock builds use Zipp Service Course / SL posts); "Seat Post Dropper compatible" (thegravelbikegeometryproject lists stealth dropper YES); seat collar 34.9 mm Gloria alloy included; front mech clamp 34.9 mm; chainring clearance up to 48/31 2x or 46t 1x. Max tyre: "Frame Tyre clearance: 29x2.1, optimised for 700x50c" (road.cc: 2.1 in = 53 mm on 700c). Wheel size: 700c / 29 in on every frame size (stock builds use Zipp 303s XPLR with Vittoria Mezcal 29x2.1 or DT Swiss G1800 with 45c tyres); no 650b option is published. RIDER HEIGHT GUIDE (official, https://gloriacycling.com/pages/sizing-chart-all-gravel): 49 = 5ft2 to 5ft4 (155-162 cm); 52 = 5ft3 to 5ft7 (160-170 cm); 54 = 5ft6 to 5ft10 (168-178 cm); 56 = 5ft9 to 6ft2 (175-188 cm); 58 = 6ft1 to 6ft4 (184-193 cm); 60 = 6ft3 to 6ft7 (190-200 cm); Gloria also offers a CAD drawing with a recommended size by email (shop@gloriacycling.com). The official size-finder web app (https://gloriatitaniumgravel.lovable.app, embedded on the builder page) uses slightly different bands with inseam and saddle-height ranges (cm): 49 = height 155-162, inseam 71-74, saddle height 60-64; 52 = 162-169, 73-77, 63-68; 54 = 169-177, 76-81, 68-75; 56 = 176-185, 80-86, 72-77; 58 = 184-189, 84-88, 75-81; 60 = 190-200, 87-91, 80-86 (values read from its JS bundle /assets/index-B95bSXLs.js). Secondary confirmations of the size table: Cyclist (https://www.cyclist.co.uk/news/gloria-titanium-all-gravel-bike) and road.cc (71.5 HTA, 74 STA, six sizes 49-60, 525-594.1 mm ETT).
